| Parameter | Value |
| Pixel Pitch | 3.076mm |
| LED Type | SMD1415 |
| Module Resolution (W*H) | 104X52=5408 Pixels |
| Pixel Density (pixel/sq.m.) | 105625 dot/㎡ |
| Module Size (W*H*D) | W320mmxH160mmxD18.4mm |
| Module Weight | 0.43±0.02kg |
| HUB | HUB75 |
| Single-dot-Brightness Calibration | Support |
| Brightness | 4500~5000 cd/㎡ |
| Color Temperature | 6500K (1000K～9500K Adjustable ) |
| Beam Angle (Hor/Ver) | 140°/140° |
| Brightness/Color Uniformity | ≥98% |
| Contrast Ratio | 5000:1 |
| Input Power <Max> | 879 W/㎡ |
| Input Power <Typical> | 293 W/㎡ |
| Power Supply Input Voltage | AC90～132V/ AC186～264V, Frequency 47-63（Hz） |
| Frame Changing Frequency | 60Hz |
| Refresh Rate | 3840Hz |
| Processing Depth | 12~14Bit |
| Video Support | 2K HD, 4K UHD |
| Life Span (hrs) | 100000hrs |
| Working Temp/Humidity(C/RH) | -20℃~50℃ / 10%~80%RH (No Condensation) |
| Storage Temp/Humidity(C/RH) | -20℃~55℃ / 10%~85%RH (No Condensation) |
| Certification | BIS/CE/CB/ROHS/EAC |
